Risen Mono PERC 545Wp Titan Solar Panel

Risen Mono PERC 545Wp Titan Solar Panel

€189,00 EUR
€189,00 EUR
Sale Sold out
Tax included. Shipping calculated at checkout.

Risen monocrystalline solar panel 545 Wp - TITAN110-8-545M (110 split cells)

545Wp Risen monocrystalline photovoltaic module with PERC (Passive Emitter Rear Cell) technology with 20.9% module efficiency. This Risen solar panel has a positive power tolerance of 0/+5W ideal for grid-connected installations with limited space where space and power per square meter is a priority with operating voltages up to 1500V in series.

The TITAN110-8-545M 545Wp solar panel is a very high power panel manufactured by the prestigious Risen brand (Tier-1) with a 12 year product warranty and 25 years of production with linear degradation of the solar panel. Panel of great power and size that reduces the cost of mounting structures.


Volume discount contact us.

The Risen TITAN 545W panel stands out for its great advantages:

  • - Solar panel with passivated solar cells back emitter which endows it with high efficiency (>20%) compared to standard cells.
  • - The lowest temperature coefficient in the industry, which improves its performance at high temperatures.
  • - High-quality encapsulation reduces PID effect and improves solar panel durability over its lifetime.
  • - Solar panel with better performance in partial shading situations due to 110 cells and 3 by-pass diodes
  • - Double inspection by electroluminescence at the production site
  • - Split cells provide better performance due to shorter bus bar length generated by electron recombination
  • - Annual degradation less than 0.55%.
  • - Smaller 110 panel size cells reach lower temperature as their internal current is lower which helps to minimize hot spots.
  • - Less formation of micro-cracks in the cells as they are smaller, which favors the production of solar energy throughout the lifetime of the solar panel.
  • - Tempered glass with anti-reflective and anti-adhesive coating improves solar panel performance in harsh environmental conditions.
  • - Solar panel capable of withstanding high mechanical static-snow loads up to (5400Pa) and dynamic-wind loads up to (2400Pa).

This solar panel is undoubtedly one of the most powerful, competitive and efficient on the market with the guarantee of Risen being one of the first manufacturers of solar panels in the world. For any questions or queries please contact our technical team.

Features: STC (1000 W/m2; T cell of 25ºC):

Model

RSM110-8-545M

Peak power (Wp)

545

Max power tolerance

0/+5W

Voltage at maximum power Vmpp (V)

31,66 V

Maximum power current Ampp (A)

17,22 A

Open circuit voltage (Voc)

38,02 V

Short circuit current (Isc)

18,23 A

Module efficiency (%)

20,90%

# of cells

110 Monocrystalline

Module dimensions

2384 x 1096 x 35 mm

Weight

29 kg

Glass

3,2 mm tempered glass

Frame

Anodized aluminum silver color

J-Box

IP68 with 3 bypass diodes

Cables

PV cable 4 mm2

Connectors

MC4 compatible
